Parts list
Column
(1 each)
Base (1 each)
Display Mount
(1 each)
12mm
55” device (6 each),
84” device (8 each)
Column Screws
stud plates (2 each)
Column Studs
25mm screws (2 each)
Puck Screws
35mm screws (2 each)
Securing Screws
locknuts (8 each)
Column Nuts
pucks (2 each)
Mounting Pucks
Images are not to scale.
Column door
(1 each)
