Using a 15-20 Watt soldering iron tin the points and the ends of the wires with solder. All you
need to do is make contact, don't focus on getting a large amount of solder, a wire that stays in
place is all you need there will never be any stress on the wires and it is not a race, take your time.
Use an X-Acto knife to scrape off any green board material away from the solder points. For this
fix I needed to solder two wires, start with the hardest one first (the blue one), I spent about 20
minutes trying to attach to the trace itself and gave up and decided to try to solder at the
termination point next to the orange component you see in the pic. This took about another 20
minutes to get a good connection. The second wire is easily accessible and took less than 30
seconds to complete.
