14 ScanMaker s480/s380 Supplement
D. Scanning 4" x 5" Film
To scan 4" x 5" film, use the 4" x 5" film holder, which can hold two pieces of 4" x 5"
film at a time.
1. Load the film face down inside the holder. Slide the film along the slots of the
holder until the film is fully loaded.
2. Raise the scanner lid, then place the holder with the loaded film on the scan bed.
The holder should be positioned against the top ruler of the scanner, with the
calibration window facing toward the back of the scanner.
3. To complete your scanning, follow the procedures outlined in scanning 35mm
filmstrips, from steps 3 to 10.
The calibration
window on the glass
surface should be
kept clear and free
from any obstruction
during scanning
To make sure the auto multiframe
cropping feature performs correctly,
align the holder’s front edge against the
top ruler of the scanner.
Note that the arrow marks on both the
film holder and scanner's top ruler are
pointing to each other.
