DIGITAL PROPORTIONAL R/CSYSTEM
www.microzone.cn
2.4GHz
FHSS
PWM signal:
High level is 3.3V, 14ms a cycle, output pulse width is 1000-2000us when not mixing, and 880-2120 when
mixing or trimming bias, as shown below.
Default runaway protection and customized runaway protection switching:
Factory default runaway protection value, that is, the third channel runaway protection value of 900, other
channels 1500; long press the frequency pair button on the receiver for more than 15 seconds, the receiver
indicator light flashes, can switch to user-defined runaway protection.
Ch1
Ch2
Ch3
Ch4
Ch5
Ch6
14ms
1000
1150
1300
1450
1750
1600
Ch7
2000
FM button
