USER MANUAL
IT
EN
DE
FR
ES
SINGLEPHASE 230V 50-60Hz
HF 36-40M 36 40 12.6 2.9 171 111 420 425 70 100 100 100 6
HF 36-60M/C1 36 60 12.4 2.8 321 244 614 605 60 100 100 - 15
HF 36-70M/C1 36 70 14.4 3.3 321 244 614 605 60 100 100 - 15
HF 48-30M 48 30 12.6 2.9 171 111 420 425 70 100 100 100 6
HF 48-40M/C1 48 40 11.0 2.5 321 244 614 605 60 100 100 - 15
HF 48-45M/C1 48 45 12.4 2.8 321 244 614 605 60 100 100 - 15
HF 48-55M/C1 48 55 15.1 3.5 321 244 614 605 60 100 100 - 15
HF 72-20M 72 20 12.3 2.8 171 111 420 425 70 100 100 100 6
HF 72-35M/C1 72 35 14.4 3.3 321 244 614 605 60 100 100 - 15
HF 80-20M 80 20 13.7 3.2 171 111 420 425 70 100 100 100 6
HF 80-30M/C1 80 30 13.7 3.2 321 244 614 605 60 100 100 - 15
THREE-PHASE 400 V. 50-60 Hz
HF 24-40T/C1
24 40 2.6/1.9 1.8/1.3 321 244 614 605 60 100 100 - 21
HF 24-60T/C1
24 60 3.9/2.9 2.7/2.0 321 244 614 605 60 100 100 - 21
HF 24-80T/C1
24 80 5.3/3.8 3.6/2.7 321 244 614 605 60 100 100 - 21
HF 24-100T/C1
24 100 6.6/4.8 4.5/3.3 321 244 614 605 60 100 100 - 21
HF 24-120T/C1
24 120 7.9/5.8 5.5/4.0 321 244 614 605 60 100 100 - 21
HF 24-150T/C1
24 150 9.9/7.1 6.8/5.0 321 244 614 605 60 100 100 - 21
HF 24-200T/C1 24 200 13.1/9.8 9.1/6.8 375 379 614 590 112 100 100 100 40
HF 24-240T/C1
24 240 15.8/11.8 10.9/8.2 375 379 614 590 112 100 100 100 40
HF 36-40T/C1 36 40 3.9/2.9 2.7/2.0 321 244 614 605 60 100 100 - 21
HF 36-60T/C1
36 60 5.9/4.3 4.1/3.0 321 244 614 605 60 100 100 - 21
HF 36-80T/C1 36 80 7.9/5.8 5.5/4.0 321 244 614 605 60 100 100 - 21
HF 36-100T/C1
36 100 9.9/7.1 6.8/5.0 321 244 614 605 60 100 100 - 21
HF 36-120T/C1
36 120 11.8/8.7 8.2/6.0 321 244 614 605 60 100 100 - 21
HF 36-150T/C1 36 150 14.8/10.7 10.2/7.4 321 244 614 605 60 100 100 - 21
HF 36-200T/C1 36 200 19.7/14.8 13.6/10.2 375 379 614 590 112 100 100 100 40
HF 36-240T/C1 36 240 23.6/17.7 16.4/12.3 375 379 614 590 112 100 100 100 40
HF 48-40T/C1 48 40 5.3/3.8 3.6/2.7 321 244 614 605 60 100 100 - 21
HF 48-60T/C1
48 60 7.9/5.8 5.5/4.0 321 244 614 605 60 100 100 - 21
HF 48-80T/C1 48 80 10.5/7.7 7.3/5.3 321 244 614 605 60 100 100 - 21
HF 48-100T/C1
48 100 13.1/9.5 9.1/6.6 321 244 614 605 60 100 100 - 21
HF 48-120T/C1
48 120 15.8/11.5 10.9/8.0 321 244 614 605 60 100 100 - 21
HF 48-150T/C1 48 150 15.4/14.3 10.7/9.9 375 379 614 590 112 100 100 100 35
HF 48-200T/C1 48 200 26.3/19.7 18.2/13.6 375 379 614 590 112 100 100 100 40
HF 48-240T/C1 48 240 31.5/23.6 21.8/16.3 375 379 614 590 112 100 100 100 40
HF 72-40T/C1 72 40 7.9/5.8 5.5/4.0 321 244 614 605 60 100 100 - 21
HF 72-60T/C1 72 60 11.8/8.6 8.2/5.9 321 244 614 605 60 100 100 - 21
HF 72-80T/C1 72 80 15.8/11.5 10.9/8.0 321 244 614 605 60 100 100 - 21
HF 72-90T/C1 72 90 13.9/12.9 9.6/8.9 375 379 614 590 112 100 100 100 35
HF 72-120T/C1 72 120 23.6/17.7 16.4/12.3 375 379 614 590 112 100 100 100 40
HF 72-160T/C1 72 160 24.7/22.9 17.1/15.9 375 379 614 590 112 100 100 100 43
HF 80-40T/C1 80 40 8.8/6.4 6.1/4.4 321 244 614 605 60 100 100 - 21
HF 80-60T/C1 80 60 13.1/9.5 9.1/6.6 321 244 614 605 60 100 100 - 21
HF 80-80T/C1 80 80 13.7/12.7 9.5/8.8 321 244 614 605 60 100 100 - 24
HF 80-90T/C1 80 90 15.4/14.4 10.7/10.0 375 379 614 590 112 100 100 100 35
HF 80-120T/C1 80 120 26.3/19.2 18.2/13.3 375 379 614 590 112 100 100 100 40
HF 80-160T/C1 80 160 27.4/25.7 19.0/17.8 375 379 614 590 112 100 100 100 43
HF 96-40T/C1 96 40 10.5/7.7 7.3/5.3 321 244 614 605 60 100 100 - 21
HF 96-60T/C1 96 60 15.8/11.5 10.9/8.0 321 244 614 605 60 100 100 - 21
HF 96-70T/C1 96 70 14.4/13.5 10.0/9.3 375 379 614 590 112 100 100 100 35
HF 96-100T/C1 96 100 26.3/19.2 18.2/13.3 375 379 614 590 112 100 100 100 40
HF 96-120T/C1 96 120 31.5/23.1 21.8/16.0 375 379 614 590 112 100 100 100 40
HF 96-140T/C1 96 140 28.8/26.9 19.9/18.6 375 379 614 590 112 100 100 100 43
Mains / Rete
(±10%)
Type
Tipo
Output
Uscita
Phase Current
Max input
power
Housing dimensions
Dimensioni armadio
Mandatory free space
Spazio libero obbligatorio
Weight
Peso
L W H D E M N S
V A A (±10%) kVA mm mm mm mm mm mm mm mm kg
*THE /C1 SUFFIX ARE BMWT EFFICIENCY LABEL APPROVED. REFERENCE REPORT NO.15-2281
