Midas PRO2 Setup Guide

MUSIC Group Research UK Limited, Klark Industrial Park, Walter Nash Road,
Kidderminster. Worcestershire. DY11 7HJ. England.
Tel: +44 1562 741515. Fax: +44 1562 745371. www.midasconsoles.com.
DOC04-
DL2SUG
1 Issue A — September 2011
© 2011 MU
SIC Group IP Ltd. Technical specifications and appearances are subject to change without notice and accuracy
is not guaranteed. MIDAS and KLARK TEKNIK are part of the MUSIC Group (music-group.com).
Connecting up Conexiones Connexions Conexão Anschlüsse herstellen
EN
ES
FR
PT
DE
100-240V AC~50-60Hz 150W (x2)
SUPPLYVOLTAGE
Warning:Both supply cords must be unplugged to ensure
complete de-energization of the equipment.
Attention: Les deux câbles d'alimentationdoivent être
débranchés afin d'assurer la déconnection complète de l'équipment.
1
AES50
audio
MIDI
in
MIDI
out
MIDI
thru
2
AES50
audio
3
AES50
audio
Ethernet
control
DESIGNED AND ENGINEERED IN ENGLAND
MADEIN CHINA
all
boot
mode
diagnostics
MOUNT IN RACK ONLY
N’ASSEMBLER QUE DANS UN RACK
REFER TOADDITIONAL SAFETY
INFORMATIONON TOP COVER
SE REFERER AU SUPPLEMENT
SUR LE COUVERCLE SUPERIEUR
D'INFORMATIONDE SECURITE
MUTE
ABCDEFAB
19
210
311
412
513
614
715
816
19
210
311
412
513
614
715
816
1725
1826
1927
2028
2129
2230
2331
2432
3341
3442
3543
3644
3745
3846
3947
4048
OUTPUT LED = ‘MUTE’ STATUS INPUT LED = ‘+48V’ STATUS
mono
left
right
≤48
≤16
≤8 ≤8
or
Input/Entrada/Entrées/Entrada/Eingang Output/Salida/Sorties/Saída/Ausgang
==
Powering up/down Encendido/apagado Mise sous/hors tension Ligar/Desligar
Ein/Ausschalten
EN
ES
FR
PT
DE
X
Caution: Do not switch both mains
switches on simultaneously.
Atención: Nunca encienda ambas
unidades simultáneamente.
Attention : Veillez à ne pas activer les
deux interrupteurs secteur en même
temps.
Atenção: Não ligue os dois
interruptores de alimentação em
simultâneo.
Vorsicht: Schalten Sie die beiden
Geräte nicht gleichzeitig ein.
T
T
Separate mains outlets
Salidas de corriente independientes
Prises secteurs individuelles
Separar as tomadas de corrente
Separate Netzsteckdosen
Powering up Encendido Mise sous tension Ligar Ein
EN
ES
FR
PT
DE
1
2
4
3
5
6
home > Preferences > Shutdown System > OK
Powering down Apagado Mise hors tension Desligar Ausschalten
EN
ES
FR
PT
DE
1
2
Wait until system is green ...
Espere hasta que el sistema esté en verde ...
Attendez que le système soit vert...
Aguarde até o sistema estar em verde ...
Warten Sie, bis das System grün ist ...
3
4
4. Connecting up 5. Powering up/down

Midas PRO2 Specifications

General

Sample Rate	96 kHz
Talkback	Yes
MIDI I/O	Yes
Computer Connectivity	USB, Ethernet
Processing	40-bit floating point
Recallable Preamps	Yes
Channels	64
Matrix	8 matrix buses
Display	15" TFT display
Connectivity	Ethernet, MIDI
Type	Digital
EQ Bands	4-band parametric EQ
Inputs - Mic Preamps	8 XLR
Outputs - Main	8 XLR
Effects	Reverb, Delay, Modulation, etc.
Dynamic Processing	Gate, Compressor, Limiter
Control Surface	Motorized faders, touchscreen
Power Supply	Internal
