Midas V190 User Manual

Technical Specification
Mains inlet
Mains Voltage Supply
Input Power
Output Power
Output
Operating
Temperature
Dimensions
Weight
IEC
100 - 240V AC Selectable
220
520W (Max)
190W (Max)
+18V = 4A (Max)
-18V = 4A (Max)
+48V = 400mA (Max)
0-40 C
Height 2U (86mm / 3.385”)
Width 19” Rackmount (482mm / 19”)
Depth 350 mm / 13.78”
13.0kg (28.6lbs)
Mains Voltage Ranges 100VAC = 85-110VAC
120VAC = 102-132VAC
VAC = 187-242VAC
240VAC = 204-264VAC
(Max)
(Max)
(Max)
(Max)
+12V = 2A (Max)
o
Mains Input Current
Connection
100VAC = 4.3A
6 Pin Male XLR
Pin 1 0V Analogue
Pin 2 +18V Analogue
Pin 3 -18V Analogue
Pin 4 +12V Gooseneck Light
Pin 5 +48V Phantom
Pin 6 0V Gooseneck Light
Case Chassis
120VAC = 3.7A
220VAC = 2.1A
240VAC = 1.95A
Operators Manual - 4Page
