Midea 11MSFI-A2-1301

59
Spec.
Code
2T0032300815
2T0032500630
2T0032800605
Model
MS11MU-09HRFN1-QRD0W
EMS11MU-12HRFN1-QRD0W
MS11MU-18HRFN1-QRC8W
Compressor
DA108X1C-20FZ3
DA130M1C-31FZ
DA150S1C-20FZ
Indoor fan motor
WZDK20-38G
(☆)
WZDK20-38G
(☆)
WZDK58-38G
(☆)
Outdoor fan
motor
WZDK35-38G(H)
(★)
WZDK35-38G(H)
(★)
WZDK35-38G(H)
(★)
Code
2T0032300814
2T0032500629
2T0032500647
Model
MS11M-09HRFN1-QRD1W(A)
MS11M-12HRFN1-QRD1W(A)
MS11MU-12HRFN1-QRD0W(B)
Compressor
DA108X1C-20FZ3
DA130M1C-31FZ
DA108X1C-20FZ3
Indoor fan motor
WZDK20-38G
(☆)
WZDK58-38G
(☆)
WZDK20-38G
(☆)
Outdoor fan
motor
WZDK35-38G(H)
(★)
WZDK35-38G(H)
(★)
WZDK35-38G(H)
(★)
Code
2T0033000477
Model
MS11M1-24HRDN1-QRC8W
Compressor
DA250S2C-30MT
Indoor fan
motor
RPG50C
Outdoor fan
motor
WZDK50-38G
(☆)
Note: The motor marked “★”means DC fan motor with control chip in the PCB while the ones marked “☆” means DC
fan motor with control chip in the fan motor.
2.Compressor checking
Measure the resistance value of each winding by using the tester.
Position
Resistance Value
DA108X1C-20FZ3
DA130M1C-31FZ
DA150S1C-20FZ
DA250S2C-30MT
Blue - Red
0.71Ω
(20℃)
1.77Ω
(20℃)
0.95Ω
(20℃)
0.55Ω
(20℃)
Blue - Black
