 Page 32 
L
H
300 cm / 118” or more
A
60 cm / 23.6”
or more
150 cm / 59”
o
r more
25 cm / 9.8”
o
r more
25 cm / 9.8”
or more
(unit: mm/inch)
ROWS OF SERIES INSTALLATION
The relations between H, A and L are as follows.
Outdoor Unit Dimensions
W
mm inch mm inch mm inch mm inch mm inch
HD
Mounting Dimensions
A B
805 31731-11/16 554 21-13/16 330 13 511 20-1/8 12-1/2
946 40337-1/4 810 31-29/32 410 16-5/32 673 26-1/2 15-7/8
952 40437-1/2 1333 52-1/2 415 16-11/32 634 24-35/36 15-29/32
890 35 673
26-1/2 342
13-15/32 663 26-1/8 354 13-15/16
Outdoor Unit
Installation
Unit Mounting Dimensions
The following is a list of different outdoor unit sizes and the distance between their
mounting feet. Prepare the installation base of the unit according to the dimensions below.
Outdoor Unit Types and Specifications
Split Type Outdoor Unit
W
H
A
B
D
W
H
LA
L  H
L  1/2H 25 cm / 9-13/16in or more
1/2H < L  H 30 cm / 11-13/16in or more
L > H Can not be installed
