06
1 Remove the air inlet grille. 2
part on both sides to pull it outwards, and
3
Buckle
4 It is recommended
cleaning and replacement cycle can
beadjusted according to the use
environment).
5
: align the slot
position at the bottom, and buckle up
the upper U-shaped buckle.
6 Install the air inlet grille: align the upper
two buckles and press them tightly, then
press the two sides at lower part, slowly
and gently buckle the air inlet grille.
Buckling
position
Installation Procedures
PRODUCT INSTALLATION
EN
