Midea ARU07M2AWW

Service Manual_2018-V1.0
21
Thermostat
1）Remove the rotary knob，the cap and screw on the
thermostat-box assembly
2）Remove the connector and dismantle the
thermostat-box assembly
3）Remove the thermostat-box panel
4） Loosen the thermostat fastening screw
5）Remove the thermostat-box cover and replace
the thermostat.
8.7 Compressor case
Rear cover and compressor case
Rear cover
None
Compressor and the cooling system pipe
