Midea ARU07M2AWW

Service Manual_2018-V1.0
23
5）Remove the clipping strip
Slowly pull it out
6）Remove the protective cover
-Pry the protective cover slowly from the upper part,
-Pull it out and remove it.
7）Remove the starter and protector
Unplug the starter and protector (you can use a
screwdriver to pry it slowly)
8）Loosen the screw of the compressor bottom plate,
remove the floor together with the compressor from the
box.
