MSMA1A-09HRN1 / MOAB02-09HN1
Cooling
COOLING OUTDOORTEMPERATUREDRY
IndoorConditions
21ºC 25ºC 30ºC 35ºC 40ºC 45ºC
21ºCD
15ºCW
TotalcapacitykW 2,43 2,41 2,39 2,34 1,87 1,76
SensitivecapacitykW 1,95 1,93 1,91 1,87 1,50 1,40
InputkW. 2,63 2,61 2,59 2,54 2,61 2,72
24ºCD
17ºCW
TotalcapacitykW 2,49 2,47 2,44 2,39 1,91 1,79
SensitivecapacitykW 1,99 1,97 1,95 1,91 1,53 1,44
InputkW. 0,83 0,82 0,82 0,80 0,82 0,86
27ºCD
19ºCW
TotalcapacitykW 2,74 2,71 2,68
2,63
2,10 1,97
SensitivecapacitykW 2,19 2,17 2,15 2,10 1,68 1,58
InputkW. 0,85 0,84 0,84
0,82
0,84 0,88
32ºCD
23ºCW
TotalcapacitykW 3,06 3,03 3,00 2,95 2,36 2,21
SensitivecapacitykW 2,45 2,43 2,40 2,36 1,89 1,77
InputkW.
0,95 0,94 0,94 0,92 0,95 0,98
Heating
HEATING OUTDOORCONDITIONS
IndoorConditions
24ºCD
 18ºCW
12ºCD
 11ºCW
7ºCD
6ºCW
4ºCD
3ºCW
0ºCD
‐1ºCW
‐5ºCD
‐6ºCW
‐7ºCD
‐8ºCW
15ºC
CapacitykW
3,56 3,52
3,09
2,53 2,16 1,70 1,57
InputkW. 0,99 0,97 0,85 0,79 0,77 0,68 0,66
18ºC
CapacitykW
3,40 3,37
2,95
2,42 2,06 1,62 1,50
InputkW. 0,94 0,93 0,81 0,75 0,74 0,65 0,63
20ºC
CapacitykW
3,21 3,17 2,78 2,28 1,95 1,53 1,42
InputkW. 0,89 0,88 0,77 0,71 0,70 0,61 0,60
22ºC
CapacitykW
2,73 2,70
2,36
1,94 1,65 1,30 1,21
InputkW. 0,82 0,81 0,71 0,66 0,64 0,57 0,55
27ºC
CapacitykW
2,73 2,70
2,36
1,94 1,65 1,30 1,21
InputkW.
0,83 0,82
0,72 0,66 0,65 0,57 0,56
