Midea BREEZELESS User Manual

Installation
 Page 34 
Connecting pipe assembly
Liquid side
Φ6.35 (1/4in)
Parts you must purchase.
Consult the dealer about
the pipe size.
Φ9.52 (3/8in)
Gas side
Φ9.52 (3/8in)
Φ12.7 (1/2in)
Φ16 (5/8in)
Φ19 (3/4in)
Magnetic ring and belt(if supplied ,please
refer to the wiring diagram to install it on
the connective cable. )
1 2 3
Pass the belt through
the hole of the Magnetic
ring to fix it on the cable
Varies by models

Midea BREEZELESS Specifications

General

Type	Split System
Refrigerant	R32
HSPF Rating	10.0
Power Supply	220-240V, 50Hz
Operating Temperature	Heating: -15-24°C
Features	Self-Cleaning, Sleep Mode, Turbo Mode
