Fig.3.6
Single air conditioner control area: control the single air conditioner. Choose a single air
conditioner and set mode, wind speed and temperature.
Single control area: to choose a single air conditioner, set mode, wind speed, temperature
and click “Apply” to carry out a single controlling function.
Group control area: to choose the corresponding group control button and carry out group
controlling. All the indoor units under the control of modbus gateway carry out this
operation.
Single Air
Conditioner
Control Area
Group control
of cooling
system
