Pull down the screw, open the shutter.
Compressor and the cooling system pipe
1）Cut off the compressor pipeline.-❶Cut off the
process pipeline.-❷Cut off the low-pressure
muffler.-❸Cut off the high-pressure exhaust pipe.
2-1）Remove the screws(for some models)
-Two screws outside
-One screw inside
2-2）Remove the metal clamp(for some models)
-Disassembly the metal clamp that is fix the electric
appliance shield
3）Remove the clipping strip
Slowly pull it out
