Midea CHEST FREEZER Series

Service Manual_2018-V1.0
23
4-1）Remove the screws(for some models)
-Two screws outside
-One screw inside
4-2）Remove the metal clamp(for some models)
-Disassembly the metal clamp that is fix the electric
appliance shield
5）Remove the starter and protector
Unplug the starter and protector (you can use a
screwdriver to pry it slowly)
6）Loosen the screw of the compressor bottom plate,
remove the floor together with the compressor from the
box.
