Destuffing
1） Pull down the screw, open the shutter.
2）Take out of temperature control box assembly by
pressing shrapnel with the hands. Note:there are four
shrapnels separately in the four corners,require enough
strength to press shrapnel. Suggest pressing one and
pushing toward the corner, as the above one by one.
3）Take out of temperature control box assembly after
four corner pushed out.
