Midea CHEST FREEZER Series

Service Manual_2018-V1.0
28
4） Remove the control box screw, take out the control
box cover
5）Pull out the wiring harness and indicator light
6）Pull out the control knob
7）Pull out the fixed nut of the thermostat
8） remove the indicator light and thermostat, the
reverse operation is for assembly
