Midea COMPACT Series User Manual

Service Manual_2018-V1.0
23
11）Replace the compressor and welding the compressor
pipeline.-❿Welding the process pipeline.-⓫Welding the
low-pressure muffler.-⓬Welding the high-pressure
exhaust pipe.
12）Replace the filter, Cu-Fe tubes welding ⓭ used Ag
welding rod, Cu-Cu tubes welding⓮ used Cu welding
rod.
13）Vacuum system,The degree of vacuum below 6Pa.
14）Perfusion refrigerant.
15）Use the vise grip pliers clamp the middle of the
process pipe, then seal welding process tube⓯⓰.
Condenser fan motor
Condenser fan motor
None

Midea COMPACT Series Specifications

General

Brand	Midea
Series	COMPACT Series
Reversible Door	Yes
Separate Freezer Compartment	Yes
Adjustable Legs	Yes
Door Style	Single Door
Refrigerant	R600a
Adjustable Thermostat	Yes
Interior Light	Yes
Energy Star Certified	Yes
Color	White
Dimensions (H x W x D)	Varies by model
Weight	Varies by model
Type	Refrigerator
