Midea CS11M-18HRFN1-MT0W

69
3) Disconnect the
connector for fan motor
from the electronic control
board.
4) Remove the four fixing
screws of the fan motor.
Then remove the fan
motor.
3
Electrical
parts
How to remove the
electrical parts.
1) After finish work of
item 1 and item 2, remove
the connectors for the
compressor and reactor.
○
1
○
3
○
4
