Cassette Units (24K, 36K, 48K)
840
840
950
950
C
Test mouth &
Test cover
Drain hole
32
Wiring connection port
680
780
780
680
136
126
91
196
132
A
A
B
A
A
B
A
A
B
A
B
Service hole for
draining pump
Fresh air intake
75
55
80
80
4-install hanger
Gas side
Liquid side
E-parts box
135
90
Panel
Body
92929292
D
D
92 92
D
D
D
D
92
9292
92
92 92
92
92
D
D
Capacity (Btu/h)
A
B
C
D
24K
mm
160
75
205
50
inch
6.30
2.95
8.07
1.97
36K
mm
160
95
245
60
inch
6.30
3.74
9.65
2.36
