Midea FLOOR TYPE User Manual

5
Wall Mounting Installtion
Chart 5
E. Connecting point of
refrigerant pipe
(D. gas side)
D. Connecting point of
refrigerant pipe
(E. Liquid side)
Drain point
Hook
Chart 6
Washer
1.Fix the hook with tapping screw onto the wall.(Refer to Chart 6)
2.Hang the indoor unit on the hook.
Tapping screw
<6mm
Hook
