维修手册 Service Manual, 2017 v1.0
10 / 13
3.9 机身的安装 Super cool
先拧松扇盒后部的螺钉或旋钮，将扇盒底部
插到立柱管内管上，并拧紧螺钉或旋钮
3.10 后网罩的安装 Super cool
将后网罩穿过电机轴放置在电机前壳上并对
好位，使用网罩索母紧固，部分网罩在穿过
电机轴后将网罩从上往下安装，并顺时针拧
动旋钮固定
3.11 风叶的安装 Super cool
将扇叶穿过电机轴，使用风叶索母逆时针固
定风叶
3.12 前网罩的安装 Super cool
将前网套入网箍，扣上网扣，在打紧网箍螺
钉
