9 Tilt angle adjustment
To adjust the air flow upward or downward, push the grilles lightly to the desired
direction.
10 Oscillation control
To make the fan oscillate, press the clutch knob located on the top of the motor
housing. To get the directional airflow, pull the clutch knob up to its initial position.
8.2 Press the grills in order with both hands. A sound of “click” will be heard when
installed right.
8.3 Self-Catch Installation.
Pa!
A straightly placed Logo indicates the
grills have been correctly aligned.
Tilt Adjustment
Pull-up for static
Swing Pull-knob
Push-down to swing
