Midea FZ10-19BRA

Circuit Diagram
N
L
Black
Red
Grey
Orange
Thermal
protector
Synchronous
motor
Battery Installation
Locking latch
Pull Notch
Considerate Hint:
1. Install the battery with positive side facing up.
2. Effective Range of Remote Control: within 5m
distance and 30-degree deflection in front of
Product.
CR2032
Battery, 3v
It uses one button battery of type "CR2032".
