M thermal Split
32 202004
Midea M thermal Split
Service Manual
1 Electric Control Box Layout
1.1 Outdoor Unit Electric Control Box Layout
Figure 4-1.1: MHA-V4(6)W/D2N8-B electric control box
Main PCB
Inverter module
Figure 4-1.2: MHA-V8(10)W/D2N8-B electric control box
Main PCB
Inverter module
Figure 4-1.3: MHA-V12(14,16)W/D2N8-B electric control box
Midea CAC
Confidential
