When a wire controller is needed, a small 5-way terminal should be added,x an infrared
emitter with gumwater near the receiver on the switch board. Connect its anode and
cathode to A and B,and +5V, GND, RUN to C, D, E on the switch board.
6. NAME AND OPERATION OF THE BUTTON ON THE
WIRE CONTROLLER
MODE BUTTON
TIMER ON BUTTON
TIMER OFF BUTTON
FOLLOW ME BUTTON
RESET BUTTON
ELECTRICAL HEATER
BUTTON
ON / OFF BUTTON
ADJUST BUTTON ▲
ADJUST BUTTON ▼
SWING BUTTON
SLEEP BUTTON
FAN SPEED BUTTON
LOCK BUTTON
