M‐ThermalSplit
10201909
MideaM‐ThermalSplitServiceManual
1.2 HydronicBoxLayout
Figure2‐1.5:SMK‐60/CGN8,SMK‐80/CGN8obliqueview
A
ir purge val
v
e
Expansionvessel
Safety valve
Waterflow switch
Waterpump
Manometer
Watersideheat exchanger
Electriccontrolbox
