M-Thermal Split
26 201909
Midea M-Thermal Split Service Manual
7 Role of Temperature Sensors in Control Functions
Figure 3-7.1: Location of the temperature sensors on M-Thermal Split systems
Notes:
1. The names and functions of the temperature sensors labelled 1 to 11 in this figure are detailed in Table 3-7.1.
Figure 3-7.1:Location of the temperature sensors onM -Thermal Splitsystems
Notes:
