16
5.1 REMOTE CONTROLLER INSTALLATION
WARNING
DO NOT locate the remote controls where they may come into contact with water.
DO NOT position the remote controls in the vicinity of chemicals.
DO NOT position the remote controls over a heat generating appliance (i.e. cooker, toaster)
DO NOT position the remote controls where materials may spill onto them.
PLEASE NOTE IF THE CONTROLS ARE TO BE FITTED TO A METAL SURFACE AN
INSULATION PLATE SHOULD BE PROVIDED BEHIND THE MOUNTING POSITION.
!
The remote controller shall be connected by a cable with the specifications below:
a. Minimum 18AWG wire
b. Maximum run of 60m
Ɣ
Attach the remote control to the wall with screws supplied.
Ɣ
83mm
102mm
Ɣ
Ɣ
Ɣ
Ɣ
Ɣ
