Putty

Trap

Note: DO NOT allow water to enter the remote control. Use the trap and putty to seal the wires.

• For exposed mounting, cut holes on four of the sides according to the picture below.

Cut three holes

for wire outlet

Cut one holes

for wire outlet

• For shielded wiring, please refer to the picture below.

Diameter of wall hole: Φ 2cm

Embedded switch

box wiring

Wiring hole

Wiring through the wall

Wall hole and wiring hole
