Product Features
Page 94
3.2.2 LCD Wired Remote Controller KJR-120C/TF-E(Optional)
The KJR-120C/TF-E wired remote controller is optional for all types.
i) Buttons and Functions
N
O
P
Q
RS
T
U
V
NM
NN
NO
NP
ëï áåÖ
ëï áåÖ
1. POWER button
Turn on of turn off the unit.
2. MODE(A/B) button
Used to select the operation mode:
Auto / Cooling /
Drying /
Heating / Fan;
Hold to active the operation of auto-lifting panel when off
3. Adjust button
To set temperature, time and timer; set up or down the
auto-lifting panel
4. FAN SPEED button
Used to select the fan speed.
5. Up-down airflow direction and swing Button
Press for adjusting the angel of louver, hold for vertical
swing; individual louver control for cassette panel
6. Left-righ airflow swing Button
Press for activing the horizontal swing
7. FOLLOW ME(PTC) button
Allows the remote control to act as a remote thermostat
and send temperature information from its current
location.
8. TIMER button
To set timer on and timer off time of one day
9. DELAY/DAY OFF button
To set 1 to 2 hours delay off for each day or a whole day off
in a weekly timer schedule
10. CONFIRM button
To confirm an setting or call up the menu
11. BACK button
Back to previous operation or superior menu
12. COPY button
Copy timer setting of one day to another in weekly schedule
setting
13 Infrared remote receiver (on some models)
