DM15-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 13
Outdoor Model M5OC-36HFN1-Q
Power supply V-ph-Hz 220-240V- 50Hz, 1Ph
Single Double Three FOUR
FIVE
Cooling
Capacity kW
2,05-5,28 4,10-7,33 6,15-8,79 8,21-10,55
10,55
Input W
1330-1780 3280
Rated current A
5.8-7.8 14,6
EER
/ / / / 3.22
Heating
Capacity kW
2,05-5,28 4,10-7,62 6,15-9,38 8,21-11,72
12,31
Input W
1650-2500 3400
Rated current A
7.2-11.0 15,3
COP
/ / / / 3,62
Max. input consumption W 4900
Max. input current A 22.0
Compressor
Model TNB306FPGMC-L
Type Twin-rotary
Brand MITSUBISHI
Capacity Btu/h 33711
Input W 3010
Rated current(RLA) A 13.5
Locked rotor Amp(LRA) A -----
Thermal protector position -----
Capacitor μF -----
Refrigerant oil ml FV50S/1070
Outdoor fan
motor
Model WZDK180-38G
Qty 1
Output W 180
Capacitor μF - -
Speed(Hi/Med/Lo) r/min 850
Outdoor coil
Number of rows 2
Tube pitch(a)* row pitch(b) mm 22x19.05
Fin spacing mm 1.5
Fin type Hydrophilic aluminium
Tube outside dia.and type mm Φ7.94,inner groove tube
Coil length * height * width mm 893x902x38.1
Number of circuits 8
Outdoor air flow m3/h 5500
Outdoor sound pressure level dB(A) 64
Outdoor sound power level dB(A) 68
Throttle type Capillary+EXV
Outdoor unit
Dimension(WxDxH) mm 990x345x965
Packing(WxDxH) mm 1120x435x1100
Net/Gross weight kg 80/91
Refrigerant
Type R410A
GWP 2088
Charged quantity Kg 3.0
Design pressure MPa 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch) 5 x Φ6.35/Φ9.52(1/4"/3/8")
Max. length for all rooms m 75
Max. length for one indoor unit m 30
