DM15-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 5
3. Specification
Outdoor Model M2OD-16HFN1-Q M2OD-18HFN1-Q
Power supply V-ph-Hz 220-240V- 50Hz, 1Ph 220-240V- 50Hz, 1Ph
Single Double Single Double
Cooling
Capacity kW 1,47-3,52 4,81 2,05-4,69 5,28
Input W / 1480 / 1650
Rated current A / 6,5 / 7,55
EER / 3,24 / 3,2
Heating
Capacity kW 1,76-3,81 4,75 2,35-4,98 5,57
Input W / 1230 / 1550
Rated current A / 5,4 / 7,1
COP / 3,87 / 3,6
Max. input consumption W 2400 2950
Max. input current A 11 14
Compressor
Model ASN108D22UEZ DA130M1C-31FZ
Type ROTARY ROTARY
Brand GMCC GMCC
Capacity Btu/h 11072 13443
Input W 827 1005
Rated current(RLA) A 5.85 3.95
Locked rotor Amp(LRA) A --- ----
Thermal protector position --- ----
Capacitor μF --- INTERNAL
Refrigerant oil ml ESTER OIL VG74 370 ESTER OIL VG74/480
Outdoor fan
motor
Model WZDK40-38G-W-1 WZDK40-38G-W-1
Qty 1 1
Output W 40(Output) 40(Output)
Capacitor μF - - - -
Speed(Hi/Med/Lo) r/min 800 800
Outdoor coil
Number of rows 2 2
Tube pitch(a)* row pitch(b) mm 25.4x22 25.4x22
Fin spacing mm 1.4 1.4
Fin type Hydrophilic aluminium Hydrophilic aluminium
Tube outside dia.and type mm Φ9.52,innergroove tube Φ9.52,innergroove tube
Coil length * height * width mm 865x508x44 865x508x44
Number of circuits 4 4
Outdoor air flow m3/h 2100 2100
Outdoor sound pressure level dB(A) 56 56
Outdoor sound power level dB(A) 65 65
Throttle type Capillary+EXV Capillary+EXV
Outdoor unit
Dimension(WxDxH) mm 810x310x558 810x310x558
Packing(WxDxH) mm 930x400x615 930x400x615
Net/Gross weight kg 34.5/37.5 36.5/39.5
Refrigerant
Type R410A R410A
GWP 2088 2088
Charged quantity Kg 1.7 2.0
Design pressure MPa 4.2/1.5 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch) 2 x Φ6.35/Φ9.52(1/4"/3/8") 2 x Φ6.35/Φ9.52(1/4"/3/8")
Max. length for all rooms m 30 30
Max. length for one indoor unit m 20 20
