Page #30 background imageLoading...
Page #30 background image
Service manual DM15-01.01.11-01en
30 Multi DC inverter R410A. Outdoor unit
7.6 Indoor unit combination for M5OD-42HFN1-Q
One Unit Two Unit Three Unit
7 7+7 9+9 7+7+7 7+9+24 9+9+24 12+18+18
9 7+9 9+12 7+7+9 7+12+12 9+12+12 18+18+18
12 7+12 9+18 7+7+12 7+12+18 9+12+18
18 7+18 9+24 7+7+18 7+12+24 9+12+24
24 7+24 12+12 7+7+24 7+18+18 9+18+18
12+18 7+9+9 9+9+9 12+12+12
12+24 7+9+12 9+9+12 12+12+18
18+18 7+9+18 9+9+18 12+12+24
Four Unit
7+7+7+7 7+7+9+24 7+9+9+24 7+12+18+18 9+9+18+18
7+7+7+9 7+7+12+12 7+9+12+12 9+9+9+9 9+12+12+12
7+7+7+12 7+7+12+18 7+9+12+18 9+9+9+12 9+12+12+18
7+7+7+18 7+7+12+24 7+9+12+24 9+9+9+18 12+12+12+12
7+7+7+24 7+7+18+18 7+9+18+18 9+9+9+24 12+12+12+18
7+7+9+9 7+9+9+9 7+12+12+12 9+9+12+12
7+7+9+12 7+9+9+12 7+12+12+18 9+9+12+18
7+7+9+18 7+9+9+18 7+12+12+24 9+9+12+24
Five Unit
7+7+7+7+7 7+7+7+9+18 7+7+9+12+18 7+9+9+12+18 9+9+9+12+12
7+7+7+7+9 7+7+7+12+18 7+7+12+12+1 8 7+9+12+12+12 9+9+9+12+18
7+7+7+7+12 7+7+7+18+18 7+9+9+9+9 7+9+12+12+18 9+9+12+12+12
7+7+7+7+18 7+7+9+9+9 7+9+9+9+12 9+9+9+9+9 9+12+12+12+12
7+7+7+7+24 7+7+9+9+12 7+9+9+9+18 9+9+9+9+12 12+12+12+12+12
7+7+7+9+9 7+7+9+9+18 7+9+9+12+12 9+9+9+9+18
7+7+7+9+12
