DM15-01.01.11-01en Service manual
Multi DC inverter R410A. Outdoor unit 9
Outdoor Model M4OD-28HFN1-Q
Power supply V-ph-Hz 220-240V- 50Hz, 1Ph
Single Double Three FOUR
Cooling
Capacity kW 1,47-4,40 352-6,16 5,28-7,03 8,21
Input W 1334-1784 1730-2403 2234-2777 2470
Rated current A 5.8-7.8 7.5-10.7 9.7-12.1 11.2
EER / / / 3.32
Heating
Capacity kW 1,47-4,40 3,52-6,16 5,28-7,91 9,09
Input W 1656-2520 2131-3419 2959-3515 2440
Rated current A 7.2-11.0 9.3-14.9 12.9-15.3 11.1
COP / / / 3.72
Max. input consumption W 3700
Max. input current A 17
Compressor
Model DA250S2C-30MT
Type Twin-rotary
Brand GMCC
Capacity Btu/h 26289
Input W 2120
Rated current(RLA) A 8.85
Locked rotor Amp(LRA) A /
Thermal protector position /
Capacitor μF /
Refrigerant oil ml ESTER OIL VG74/820
Outdoor fan
motor
Model WZDK72-38G
Qty 1
Output W 72(Output)
Capacitor μF /
Speed(Hi/Med/Lo) r/min 800
Outdoor coil
Number of rows 2
Tube pitch(a)* row pitch(b) mm 22x19.05
Fin spacing mm 1.4
Fin type Hydrophilic aluminium
Tube outside dia.and type mm Φ7.94,innergroove tube
Coil length * height * width mm 766x814x38.1
Number of circuits 4
Outdoor air flow m3/h 3800
Outdoor sound pressure level dB(A) 62
Outdoor sound power level dB(A) 70
Throttle type Capillary+EXV
Outdoor unit
Dimension(WxDxH) mm 900x315x860
Packing(WxDxH) mm 1043x395x915
Net/Gross weight kg 65/69
Refrigerant
Type R410A
GWP 2088
Charged quantity Kg 2.4
Design pressure MPa 4.2/1.5
Refrigerant
piping
Liquid side/ Gas side mm(inch) 4 x Φ6.35/Φ9.52(1/4"/3/8")
Max. length for all rooms m 60
Max. length for one indoor unit m 30
