Service manual DM16-01.01.11-01en
16 Multi DC inverter R410A. Outdoor unit
7. Indoor units combination
7.1 Indoor unit combination for M2OE-14HFN1-Q
One unit Two unit
7 7+7 9+9
9 7+9 9+12
12 7+12
18
7.2 Indoor unit combination for M2OF-18HFN1-Q
One unit Two unit
7 7+7 9+9
9 7+9 9+12
12 7+12 9+18
18 7+18 12+12
7.3 Indoor unit combination for M3OE-21HFN1-Q
One unit Two unit Three unit
7 7+7 9+9 7+7+7 7+9+12
9 7+9 9+12 7+7+9 9+9+9
12 7+12 9+18 7+7+12 9+9+12
18 7+18 12+12 7+9+9 7+12+12
7.4 Indoor unit combination for M3OE-27HFN1-Q
One unit Two unit Three unit
7 7+7 9+9 12+18 7+7+7 7+9+9 7+12+18 9+12+12
9 7+9 9+12 18+18 7+7+9 7+9+12 9+9+9 9+12+18
12 7+12 9+18 7+7+12 7+9+18 9+9+12 12+12+12
18 7+18 12+12 7+7+18 7+12+12 9+9+18
7.5
Indoor unit combination for M4OE-28HFN1-Q
One unit Two unit Three unit Four unit
7 7+7 9+9 12+18 7+7+7 7+9+9 7+12+18 9+12+18 7+7+7+7 7+7+9+9 7+9+9+12
9 7+9 9+12 12+24 7+7+9 7+9+12 9+9+9 12+12+12 7+7+7+9 7+7+9+12 7+9+12+12
12 7+12 9+18 18+18 7+7+12 7+9+18 9+9+12 12+12+18 7+7+7+12 7+7+9+18 9+9+9+9
18 7+18 12+12 7+7+18 7+9+24 9+9+18 7+7+7+18 7+7+12+12 9+9+9+12
24 7+24 9+24 7+7+24 7+12+12 9+12+12 7+9+9+9
To Next Page
