Installation
Page 107
Accessories-Compact cassette type:
Name Shape Quantity
Indoor unit installation
Installation paper template
(some models)
1
Refrigeration Fittings
Soundproof/insulation sheath
(some models)
1
Drainpipe Fittings
Outlet pipe sheath(some models) 1
Outlet pipe clasp(some models) 1
Drain joint (some models) 1
Seal ring (some models) 1
Installation Accessory
(some models)
Ceiling hook 4
Copper nut(some units)
Used to make the connective pipes
between indoor and outdoor units.
Suspension bolt 4
Orifice tube (some units) 1
Anti-shock rubber 1
EMC Magnetic
Ring (some models)
Magnetic ring (wrap the electric wires
S1 & S2 ( P & Q & E ) around the
magnetic ring twice)
S1&S2(P&Q&E)
1
Magnetic ring (Hitch it on the
connective cable between indoor unit
and outdoor unit after installation.)
1
Others
Owner‘s manual - 1
Installation manual - 1
Optional accessories:
• There are two types of remote controls: wired and wireless.
• Select a remote controller based on customer preferences and requirements and install in an appropriate place.
• Refer to catalogues and technical literature for guidance on selecting a suitable remote controller.
