Installation
Page 111
Installation Order-Compact cassette type
LN
1
2
3
4
5
MC MC
6
7
8
Install the indoor unit Install the outdoor unit Install the drainpipe
Evacuate the refrigeration system Connect the wires Connect the refrigerant pipes
Install the front panel Perform a test run
