Midea MAD160-A2801GPS

Service manual for Washing Machine Midea America Company
-------------------------------------------------------------------------------------------------------------------------------------------------------
－ 19 －
4.4 Wiring diagram and terminals
Wiring diagram Picture 1
Wiring diagram Picture 2
Port definition (Detail pin definition refer to Wiring diagram Picture 1)
Port
Name on PCB
Definition
CN1
Pin 1: Live line
Pin 2: Null line
CN7
CN3
CN4
CN6
CN5
CN8
CN1
CN12
