4.10 Installation of single-module water system pipeline
Fig. 4-5
MC-SU30-RN1L
Fig. 4-6
MC-SU60-RN1L
Water inlet
Water outlet
Total water outlet
temperature sensor
Electric control box
Electric control box
Water inlet
Water outlet
Total water outlet
temperature sensor
