Aqua Tempo Super II
32 201902
Midea Aqua Tempo Super II Engineering Data Book
5 Capacity Tables
5.1 Heating Capacity Tables
Table 2-5.1: MC-SU30(M)-RN1L heating capacity
Ambient
temp (°C)
Chilled water outlet temperature (°C)
30.00 35.00 40.00 45.00 50.00 55.00
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-15.00 17.38 8.03 16.06 8.22 16.80 8.60 15.35 9.65 - - - -
-7.00 25.44 8.85 24.41 9.46 24.32 9.90 23.33 11.11 20.23 11.21 - -
2.00 25.67 8.04 25.05 8.51 24.23 8.90 23.94 9.99 20.76 10.08 - -
7.00 31.84 8.17 33.80 8.95 32.95 9.36 32.31 10.51 28.01 10.60 22.19 9.20
15.00 34.27 5.35 32.23 5.77 27.58 5.86 24.21 6.64 23.54 7.93 21.97 8.70
20.00 33.69 4.51 30.77 4.67 25.45 4.63 21.57 5.10 20.87 6.08 19.43 6.73
25.00 33.75 4.18 31.22 4.34 26.34 4.31 22.82 4.78 22.62 5.77 21.61 6.38
30.00 36.13 4.75 33.14 4.58 27.18 4.78 24.69 4.99 23.15 6.13 22.14 6.85
Abbreviations:
TC: Total capacity (kW)
PI: Power input (kW)
Notes:
1. Performance specifications measured with water pump operating at rated water flow rate.
Table 2-5.2: MC-SU60(M)-RN1L heating capacity
Ambient
temp.(°C)
Chilled water outlet temperature (°C)
30.00 35.00 40.00 45.00 50.00 55.00
TC PI TC PI TC PI TC PI TC PI TC PI
kW kW kW kW kW kW kW kW kW kW kW kW
-15.00 28.07
12.66
25.94
12.96
27.23
13.35
24.87
15.51
- - - -
-7.00 43.02
15.67
42.52
16.13
40.97 18.66
39.96
18.75
34.13
19.58
- -
2.00 45.39
14.12
44.28
14.96
42.96
15.40
42.45
17.89
36.81
18.05
- -
7.00 61.57
16.10
65.37
17.64
63.91
18.16
62.67
21.09
54.34
21.28
43.04
18.47
15.00 66.27
10.54
62.32
11.37
53.50
11.38
46.97
13.33
45.67
15.93
42.61
17.46
20.00 65.14
8.90
59.50
9.21
49.37
8.97
41.84
10.24
40.49
12.21
37.69
13.52
25.00 65.26
8.23
60.37
8.54
51.09
8.36
44.26
9.60
43.87
11.59
41.91
12.81
30.00 66.38 8.51 67.12 8.74 54.25 8.94 47.97 10.02 45.86 11.99 43.22 13.23
Abbreviations:
TC: Total capacity (kW)
PI: Power input (kW)
Notes:
1. Performance specifications measured with water pump operating at rated water flow rate.
