Aqua Tempo Super II
34 201902
Midea Aqua Tempo Super II Engineering Data Book
5.2 Heating Capacity Tables
Table 2-5.4: MC-SU30(M)-RN1L
cooling capacity
Ambient
temp.
(°C)
Chilled water outlet temperature (℃)
5.00 7.00 10.00
13.00
15.00
20.00
Capacity
Power
Capacity
Power
Capacity
Power
Capacity
Power
Capacity
Power
Capacity
Power
TC PI TC PI TC PI TC PI TC PI TC PI
-10.00 22.69 6.13 25.88 6.15 28.79 6.98 31.16 6.85 32.02 7.58
32.69 7.35
-5.00 22.96 6.49 24.79
6.75
27.01
6.80
28.90
7.11
30.16
7.32
31.90
7.28
5.00 23.47 6.85 24.88
6.91
26.87
6.89
28.75
7.19
30.01
7.39
31.13
7.31
10.00
23.85 6.53 24.57
6.98
26.54
6.89
28.54
7.23
29.87
7.45
30.14
7.32
17.00
41.08 11.13
42.86
11.91
46.28
12.61
49.29
13.09
51.28
13.75
56.25
13.75
25.00
37.33 10.95
38.49
11.39
40.89
11.78
43.53
12.08
45.29
12.69
50.19
12.90
30.00
32.04 9.88 33.58
10.36
35.24
10.55
37.79
11.56
39.49
11.55
46.56 13.30
35.00
30.72 11.23
31.11
11.96
32.18
10.12
32.50
11.80
34.17
10.95
40.77 12.17
40.00
21.08 9.85 22.32
10.24
25.05 10.82
26.87 11.40
28.69
11.79
33.24 12.76
43.00 18.76 9.01 19.78 9.57 22.88 11.36
23.81 10.65
26.58 12.69
31.54 13.96
Abbreviations:
TC: Total capacity (kW)
PI: Power input (kW)
Notes:
Performance specifications measured with water pump operating at rated water flow rate.
Table 2-5.5: MC-SU60(M)-RN1L
cooling capacity
Ambient
temp.
(°C)
Chilled water outlet temperature (℃)
5.00 7.00 10.00 13.00 15.00 20.00
Capacity
Power
Capacity
Power
Capacity
Power
Capacity
Power
Capacity
Power
Capacity
Power
TC PI TC PI TC PI TC PI TC PI TC PI
-10.00 47.58 11.85
52.7 12.65
53.69 12.97
61.64 13.98
62.05 15.38
63.25 15.31
-5.00 46.58 12.58
48.27
13.66
52.60
13.76
56.08
14.31
58.69
14.80
62.08
14.73
5.00 46.06 12.68
48.46
13.98
52.32
13.94
55.81
14.46
58.41
14.95
60.58
14.78
10.00
46.25 13.52
47.86
14.12
51.68
13.94
55.56
14.56
58.14
15.06
58.66
14.79
17.00
81.58 22.56
83.34
24.04
89.97
25.47
96.42
26.84
99.67
27.76
109.32
27.77
25.00
72.12 22.14
74.86
23.00
79.52
23.80
85.18
24.70
88.05
25.62
97.56
26.05
30.00
63.89 19.89
65.34
20.94
68.56
21.31
67.52
22.48
76.79
23.32
90.50
26.85
35.00
58.63 23.18
60.54
24.16
62.62
20.45
64.30
21.38
66.47
22.12
79.27
24.57
40.00
43.85 20.58
45.45
21.06
49.30
21.61
53.16 23.28
55.73
23.65
62.15 24.57
43.00 39.68 18.96
40.28 19.68
44.83 22.35
47.12 21.75
56.32 24.15
60.28 25.39
Abbreviations:
TC: Total capacity (kW)
PI: Power input (kW)
Notes:
Performance specifications measured with water pump operating at rated water flow rate.
