 Page 7 
Unit Installation Overview
Installation Overview
3
L N
1
2
3
4
5
MC MC
6
7
8
Install the indoor unit
(Page 8)
INSTALLATION ORDER
Install the outdoor unit
(Page 12)
Install the drainpipe
(Page 14)
Evacuate the refrigeration system
(Page 22)
Connect the wires
(Page 20)
Connect the refrigerant pipes
(Page 16)
Install the front panel
(Page 24)
Perform a test run
(Page 26)
