Midea MCA3U-12FNXD0 User Manual

3
4
5
6
7
8
Operation of buttons
1
2
4
5
3
9
10
11
12
13
8
6
7
Temp
Mode Fan
OK
Timer
ECO
Turbo LED
Fav.
Options
Timer Button
Turbo Button
Press this button to initiate the auto-on/
auto-off time sequence.
The TURBO function makes the unit work
extra hard to reach your present temperature
in the shortest amount of time possible.
When you press the TURBO button in
COOL mode, the unit will blow cool air
with strongest wind setting to jump-start
the cooling process.
When you press the TURBO button in
HEAT mode, for units with Electric heat
elements, the Electric Heater will activate
and jump-start the heating process.
RG70F/BGEF
NOTE:
Pressing the ON/OFF button, or modifying
the mode or adjusting the set temperature to
O
less than 24 C will stop ECO operation.
Under ECO operation, the set temperature
O
should be 24 C or more. it may result in
insufficient cooling. If you feel uncomfortable,
just press the ECO button again to stop it.
LED Button
Used to select the fan speed in four steps:
AUTO LOW MED HIGH
Fan Button
You can not switch the fan speed in AUTO
or DRY mode.
Press Fan, MODE, Sleep, ON/OFF ,ECO or
Turbo button will cancel the Silent function.
NOTE：
Hold down this button for at least 2 seconds
to activate/cancel Silent mode. Due to low
frequency operation of compressor, it may result
in insufficient cooling and heating capacity
(applicable to the air conditioner with Silent
feature only)
Operation of buttons
9
10
11
1
2
4
5
3
9
10
11
12
13
8
6
7
Temp
Mode Fan
OK
Timer
Sleep
Turbo LED
Fav.
Options
RG70C/BGEF
RG70C1/BGEF
Swing Button
OK Button
Swing Button
Used to confirm the optional fucntions.
Used to stop or start horizontal louver move-
ment or set the desired up/down air flow
direction. The louver changes 6 degree in
angle for each press. If keep pushing more
than 2 seconds, the louver will swing up and
down automatically.
Used to stop or start vertical louver movement
and set the desired left/right air flow direction.
The louver changes 6 degree in angle for each
press. If keep pushing more than 2 seconds,
the louver will swing left and right automatically.
Options Button
12
Press this button to select the air conditioner
function in a sequence of following:
Self clean
Follow me
Fresh
Press the Options button to select the desired
function, the selected symbol will flash on
the display area, then press the OK button
to confirm.
Comfort
FRESH function( )
When the FRESH function is initiated, the
Ionizer/Plasma Dust Collector(depending on
models) is energized and will help to
remove pollen and impurities from the air.
FOLLOW ME function( )
Comfort function( )
When the Follow Me function is activated,
the remote display is actual temperature
at its location. The remote control will send
this signal to the air conditioner every 3
minutes interval until press the FOLLOW
ME button again.
When the Comfort function is activated,
O
the air conditioner will be set at 23 C
automatically. It is not available under
fan mode.
If you are sensitive to light when you go to
sleep, you can press the LED button to turn
off the LED display on the indoor unit. Press
the button again to turn it back on.
