Midea MCA3U-12HRFN1-M(C) User Manual

279
 MOX230-09HFN1-MW5W, MOX230-12HFN1-MV5W, MOX330-09HFN1-MY5W,
MOX330-12HFN1-MW5W
No.
Part name
Procedures
Remarks
1
Panel plate
How to remove the panel
plate.
1)Stop operation of the
air conditioner and turn
“OFF” the power breaker.
2) Remove the big handle
first(3 screws)
3) Remove the top
cover (4 screws)
4)Remove the screws of
front panel(9 screws)

Midea MCA3U-12HRFN1-M(C) Specifications

General

Brand	Midea
Model	MCA3U-12HRFN1-M(C)
Category	Air Conditioner
Language	English
