314
4) Disconnect the
connector for fan motor
from the electronic control
board.
5) Remove the four fixing
screws of the fan motor,
then remove the motor.
○
5
○
4
T3,T4,T5,sensor
Pressure switch
Compressor
wire
Electronic expansion
4 way valve
Motor wire
○
5
