28
MHG-60HWFN1-MW
NOTE:16 groups all around(the same
of the air inlet flange)
10
Φ5
2-Φ3.2
10
280
280
1000
500
1000
500
6
6
4 3
385
(air inlet
duct flange)
385
(air outlet
duct flange)
1188(air outlet duct flange)
1188(air inlet duct flange)
1436(suspension position)
700
(suspension position)
770
1400
1
2
460
20
44
20
44
44
20
20
44
858
