Midea MCCU-03CN1 - Specifications

Midea R410A 50Hz T1 Compressor Condensing Unit
7
4. Specifications
Model
MCCU-03CN1
MCCU-05CN1
Power supply
\
220-240V~, 1Ph, 50Hz
220-240V~, 1Ph, 50Hz
Ambient temperature range
°C
17~46
17~46
Cooling
Capacity
kW
3.2
5.3
Max. input
kW
1.60
2.85
Max. current
A
7.5
15.0
Noise level
dB(A)
29.4
44.0
Compressor
Type / Quantity
\
Rotary / 1
Rotary / 1
Model
\
PA150X2C-4FT
PA225M2CS-4KU2
Brand
\
GMCC
GMCC
Capacity
W
3,660
5,500
Input
W
1,260
1,835
Capacitor
\
35µF/450V
50µF/450V
Rated current (RLA)
A
5.8
8.5
Oil charge
\
480 (Ester oil VG74)
750 (Ester oil VG74)
Refrigerant
Type / Charged
\
R410A / 800g
R410A / 860g
Fan
Type / Quantity
\
Axial fan / 1
Axial fan / 1
Motor model
\
YDK24-6F(B)
YDK48-6H(A)
Fan dimension
mm
Φ401
Φ424
Drive type
\
Direct
Direct
Capacitor
\
2.5µF/450V
3µF/450V
Motor input
W
63
111
Motor speed
rpm
800
890
Coil
Type
\
Copper tube and aluminum fin
Copper tube and aluminum fin
Tube size
mm
Φ7.94
Φ7
No. of rows
\
1
2
Fin space
mm
1.6
1.4
Length × Height
mm
762×484
658×546
Number of circuits
\
2
8
Refrigerant
pipe
Liquid side / Gas side
mm
Φ6.35/Φ12.7
Φ6.35/Φ12.7
Max. pipe length
m
20
20
Max. difference in level
m
10
10
Connection
wire
Power wire
\
2×2.5mm
2
+1×1.5mm
2
(Ground)
2×4.0mm
2
+1×2.5mm
2
(Ground)
Signal wire
\
1×1.0mm
2
1×1.0mm
2
Dimension (W×H×D)
mm
848×549×300
825×597×315
Packing (W×H×D)
mm
910×575×335
890×650×360
Net / Gross weight
kg
30.5/33
36.5/39.5
Notes:
Nominal cooling capacities are based on the following conditions: Indoor temperature: 27°CDB/19°CWB; outdoor
temperature: 35°CDB/24°C WB. Equivalent refrigerant pipe: 7.5m.
